SQ Series Evolved

The new MIURA SQ-CS model delivers an outstanding 99% boiler efficiency, maximizing heat recovery and minimizing energy loss.

Equipped with O₂ sensor, and multi-position damper control, it ensures stable combustion and low NOx emissions.

Key Features of SQ-CS models:

- 99% boiler efficiency with redesigned economizer

- Low NOx emission (25 ppm) for a cleaner

 environment

- Inverter control for energy saving

- Boiler Operation Monitor and Status Indicator Lights

Even Higher efficiency with low emissions - the SQ-CS Series redefines performance and sustainability in industrial boilers.

The High Pressure SQ-B model

in MIURA's once-through boiler series delivers powerful output options of 3000 kg/h, 5000 kg/h, and 7000 kg/h with the efficiency of 98%.

Key Features of SQ-B models:

- Inverter-controlled fan and feed water pump,

 it achieves an impressive 98% efficiency

 while minimizing power consumption.

- 'High-speed continuous control (i-HV)' ensures

 precise combustion tracking and

 stable steam pressure

- Ultra-low NOx emission of just 30 ppm

 (O₂=0% conversion, measured with natural gas).

The SQ-B is an environmentally friendly model for high-pressure and high-output steam boiler in a single boiler unit.
